Image Content: Computer-generated images and aftermarket equipment shown throughout.

Standard Hybrid/AWD Powertrain

Available 12.1-inch Integrated Computer Screen

Available Police Perimeter Alert
Exterior Dimensions (in.)
Length
|
|
|
198.8
|
Wheelbase
|
|
|
119.1
|
Height
|
|
|
69.4
|
Width (Mirrors Folded)
|
|
|
78.9
|
Width (Mirrors Extended)
|
|
|
89.3
|
Step-In Height
|
|
|
18.6
|
Lift-over Height (Ground To Cargo Deck)
|
|
|
30.9
|
Ground Clearance (in.)
3.3L HEV
|
|
|
7.4
|
3.0L EcoBoost®
|
|
|
7.2
|
3.3L Direct-Injection V6
|
|
|
7.6
|
Interior Dimensions (in.)
|
|
Front
|
Rear
|
Head Room
|
|
40.7
|
40.4
|
Shoulder Room
|
|
61.8
|
61.3
|
Hip Room
|
|
59.3
|
59.1
|
Leg Room
|
|
40.9
|
40.7
|
Between-Seat Distance
|
|
11.3
|
|
Cargo Area Dimensions (in.)
Opening Height
|
|
|
31.9
|
Opening Width
|
|
|
47.6
|
Area Width
|
|
|
47.9
|
Area Length
|
|
|
46.2
|
Capacities
Cargo Volume/Behind Front Row
|
|
|
90.3 cu. ft.
|
Cargo Volume/Behind Second Row
|
|
|
52.0 cu. ft.
|
Cargo Capacity
|
|
|
880 lbs.
|
Total Passenger Volume
|
|
|
118 cu. ft.
|
Total Interior Volume
|
|
|
170 cu. ft.
|
Seating
|
|
|
5
|
Payload Capacity
|
|
|
1,670 lbs.
|
Towing
|
|
|
5,000 lbs.
|
GVWR / 3.3L HEV
|
|
|
6,840 lbs.
|
GVWR / 3.0L EcoBoost®
|
|
|
6,500 lbs.
|
GVWR / 3.3L Direct-Injection V6
|
|
|
6,465 lbs.
|
Engines
3.3L HEV AWD
|
|
|
Standard: EPA-estimated 23 City / 24 Highway / 24 Combined
|
3.3L Direct-Injection V6 FFV AWD
|
|
|
Available: EPA-estimated 17 City / 23 Highway / 19 Combined
|
3.0L EcoBoost® AWD
|
|
|
Available: EPA-estimated 17 City / 22 Highway / 19 Combined
|
Power
Horsepower/3.3L HEV
|
|
|
318 @ 6,500 rpm (combined system hp)
285 @ 6,500 rpm (gas engine) |
Horsepower / 3.0L EcoBoost®
|
|
|
400 @ 5,500 rpm*
|
Horsepower / 3.3L Direct-Injection V6
|
|
|
285 @ 6,500 rpm
|
Torque / 3.3L HEV
|
|
|
322 lb.-ft. @2,500 rpm (combined system torque)
260 lb.-ft.@ 4,000 rpm (gas engine) |
Torque / 3.0L EcoBoost®
|
|
|
415 lb.-ft.@ 3,000 rpm*
|
Torque / 3.3L Direct-Injection V6
|
|
|
260 lb.-ft.@ 4,000 rpm
|
*Horsepower and torque numbers achieved with premium fuel.
-
