240/320miles2
5,000/7,700lbs.
| Cab style | SuperCrew® |
|---|---|
| Pickup box style | 5.5-ft. Styleside |
| Drive system | 4x4 |
| Wheelbase | 145.5 in. |
| Overall length | 232.7 in. |
| Cab height | 78.3 in. |
| Width - Excluding mirrors | 80.0 in. |
| Width - Including standard mirrors | 96.0 in. |
| Width - Standard Mirrors folded | 83.6 in. |
| Track width - Front | 68.1 in. |
| Track width - Rear | 68.3 in. |
| Overhang - Front | 37.8 in. |
| Overhang - Rear | 49.4 in. |
| Angle of approach | 24.4 degrees |
| Angle of departure | 23.6 degrees |
| Ramp breakover angle | 17.6 degrees |
| Ground clearance | 8.4 in. |
| Front bumper to back of cab | 155.9 in. |
| Open Tailgate to Ground | 36.7 in. |
| Front trunk liftover height | 34.5 in. |
| Cargo box style | 5.5-ft. Styleside |
| Inside Length (at floor) | 67.1 in. |
| Width between wheelhouses | 50.6 in. |
| Inside Height | 21.4 in. |
| Cargo box volume | 52.8 cu. ft. |
| Cab style | SuperCrew® |
|---|---|
| Head room - Front | 40.8 in. |
| Head room - Rear | 40.4 in. |
| Shoulder room - Front | 66.7 in. |
| Shoulder room - Rear | 66.0 in. |
| Hip room - Front | 62.5 in. |
| Hip room - Rear | 62.6 in. |
| Max Leg room (SAE) - Front | 43.9 in. |
| Leg room (SAE) - Rear | 43.6 in. |
| Cab style | SuperCrew® |
|---|---|
| Maximum Seating Capacity | 5 |
| Minimum Seating Capacity | 5 |
| Cargo box volume | 52.8 cu. ft. |
| Front trunk volume | 14.1 cu.ft./400 L |
| Battery capacity - Standard Range | 98 kWh* |
| Battery capacity - Extended Range | 131 kWh* |
| *Based on manufacturer calculation using computer engineering simulations. Your results may vary. | |
| Cab style | SuperCrew® |
| Pickup box style | 5.5-ft. Styleside |
| Drive system | 4x4 |
| Base Curb Weight - Standard Range Battery | 6,015 lbs. |
| Base Curb Weight - Extended Range Battery | 6,361 lbs. |
| Base Curb Weight w/20 inch A/T Tire | 6,597 lbs. |
| Base Curb Weight Platinum | 6,893 lbs. |
| Motor type | Permanent Magnet Synchronous Motor |
|---|---|
| Motor Control System | IGBT Inverter & AC Control |
| Standard-Range Horsepower (hp@rpm) | 462 HP** |
| Extended-Range Horsepower (hp@rpm) | 580 HP** |
| Torque (lb.-ft. @rpm) | 775 lb-ft** |
Coolant Capacity Standard Range Battery w/2.4kW Pro Power Onboard (L) |
13.7 L |
Coolant Capacity Standard Range Battery w/9.6kW Pro Power Onboard (L) |
14.6 L |
Coolant Capacity Extended Range Battery w/2.4kW Pro Power Onboard (L) |
15.0 L |
Coolant Capacity Extended Range Battery w/9.6kW Pro Power Onboard (L) |
15.9 L |
| Refrigerant Amount: Base TT, Single AC System (oz) | 27oz R1234yf |
| Refrigerant Amount: Max TT, Duel A/C System (oz) | Cabin System 21.5oz R1234yf HV |
| Battery cooling system 11oz R1234yf | |
| EPA-Estimated Range (Standard-Range battery) | N/A† |
| EPA-Estimated Range (Extended-Range battery, non-Platinum) | N/A† |
| EPA-Estimated Range (Platinum Trim) | N/A† |
**Calculated via peak performance of the electric motor(s) at peak battery power. Horsepower and torque are independent attributes and may not be achieved simultaneously. Your results may vary. |
|
| †Based on full charge. Actual range varies with conditions such as external environment, vehicle use, vehicle maintenance, and lithium-ion battery age and state of health. |
| F-150 | |
|---|---|
| Front suspension | Independent double-wishbone with coil-over shock, stabilizer bar |
| Rear suspension | Independent semi trailing arms with coil-over shocks |
| Front and rear shocks | Heavy-duty gas-pressurized |
| Front: Monotube; Rear: Twin tube | |
| Friction Brakes | Power 4-wheel anti-lock vented disc |
| Steering | Rack and Pinion Electric Power-Assisted |
| SuperCrew® | ||
|---|---|---|
| Pickup Box | 5.5-ft. Box | |
| Drive Type | 4x4 | |
| GCWR (lbs.) | Towing Capacity lbs. | |
| Standard Range Battery | 11,700 | 5,000 |
| Extended Range Battery | 14,800 | 7,700 |
| Standard Range Battery with Max Tow Package | 14,400 | 7,700 |
| Extended Range Battery with Max Tow Package | 17,100 (16,700 - 20" a/t tires) | 10,000 (9,600 - 20" a/t tires) |
| Platinum | 15,900 | 8,600 |
| Max towing varies based on cargo, vehicle configuration, accessories, and number of passengers. |
| SuperCrew® | ||
|---|---|---|
| Pickup Box | 5.5-ft. Box | |
| Drive Type | 4x4 | |
| Engine | GVWR (lbs.) | lbs. |
| Standard Range Battery | 8,250 | 2,235 |
| Extended Range Battery | 8,550 | 1,952 |
| Extended Range Battery with 20" A/T Tires | 8,400 | 1,802 |
| Platinum | 8,550 | 1,656 |
| Max. payload varies and is based on accessories and vehicle configuration. See label on door jamb for carrying capacity of a specific vehicle. |
| Powertrain | Standard Range Battery | Extended Range Battery |
|---|---|---|
| Horsepower (hp@rpm) | 462 HP** | 580 HP** |
| Torque (lb.-ft. @rpm) | 775 lb-ft** | 775 lb-ft** |
| EPA-Estimated Fuel Economy Ratings - SR | N/A† | |
| EPA-Estimated Fuel Economy Ratings - ER | N/A† | |
| **Calculated via peak performance of the electric motor(s) at peak battery power. Horsepower and torque are independent attributes and may not be achieved simultaneously. Your results may vary. | ||
| †Based on full charge. Actual range varies with conditions such as external environment, vehicle use, vehicle maintenance, and lithium-ion battery age and state of health. | ||
| Available Drive Types | 4x4 | |
| Available Cab Types | SuperCrew® | |
| Max Seating Capacity | 5 | |
| Minimum Seating Capacity | 5 | |
| Wheelbase - 5.5-ft. Box | 145.4 in. | |
| Available Trims | Pro, XLT, LARIAT, Platinum | |
Maximum Conventional Towing (When properly configured) |
10,000 lbs. | |
Maximum Payload (When properly configured) |
2,235 lbs. | |
| Max towing on XLT and LARIAT models with available extended-range battery and Max Trailer Tow Pkg. Max towing varies based on cargo, vehicle configuration, accessories and number of passengers. | ||
| Max payload with Pro trim and Standard-Range battery. Max. payload varies and is based on accessories and vehicle configuration. See label on door jamb for carrying capacity of a specific vehicle. | ||
| Time | Distance | |
| Warranty - Bumper to Bumper | 3 years | 36,000 miles |
| Warranty - EV Component Warranty | 8 years | 100,000 miles |
| Warranty - Safety Restraint System | 5 years | 60,000 miles |
| Warranty - Aluminum Body Panels | 5 years | Unlimited miles |
| Warranty - Corrosion - Sheet Metal (Perforation Only Excluding Aluminum) | 5 years | Unlimited miles |
| Warranty - Paint Adhesion | 5 years | Unlimited miles |
| Warranty - Roadside Assistance Program | 5 years | 60,000 miles |
| Whichever comes first. |
