F-150 Specifications

Engine Highlights
Available Engines 2.7L EcoBoost® V6 3.5L EcoBoost® V6 3.5L Ti-VCT V6 5.0L Ti-VCT V8
Horsepower 325 @ 5750 rpm 365 @ 5000 rpm 282 @ 6250 rpm 385 @ 5750 rpm
Torque 375 @ 3000 rpm 420 @ 2500 rpm 253 @ 4250 rpm 387 @ 3850 rpm
Fuel Economy - 4x2 (city/highway/combined) 19/26/22 17/24/20 18/25/20 15/22/18
Fuel Economy - 4x2 Payload Package (city/highway/combined) 18/24/21 16/22/18 - 14/20/16
Fuel Economy - 4x4 (city/highway/combined) 18/23/20 16/22/18 17/23/19 15/21/17
Fuel Economy - 4x4 Payload Package (city/highway/combined) 18/22/19 15/20/17 - 14/19/16
Vehicle Capacity Highlights
Available Drive Types 4x2 4x4
Available Cab Types Regular Cab SuperCab SuperCrew
Max Seating Capacity 3 6 6
Wheelbase - 5.5' Box - - 145.0 in.
Wheelbase - 6.5' Box 122.4 in. 145.0 in. 156.8 in.
Wheelbase - 8' Box 141.1 in. 163.7 in. -
Available Trims XL XLT LARIAT King Ranch® Platinum Limited
Transmission - 6-Speed Automatic Standard Standard - - - -
Transmission - 6-Speed SelectShift Automatic Available Available Standard Standard Standard Standard
Maximum Conventional Towing
(When properly equipped)
12,200 lbs.
Maximum Payload
(When properly equipped) (Regular Cab 4x2 with 5.0L V8 and Heavy Duty Payload Pkg)
3,270 lbs.
Min Vehicle Base Curb Weight - 4x2 4,051 lbs.
Min Vehicle Base Curb Weight - 4x4 4,305 lbs.
Warranties
  Time Distance
Warranty - Bumper to Bumper 3 years 36,000 miles
Warranty - Powertrain 5 years 60,000 miles
Warranty - Safety Restraint System 5 years 60,000 miles
Warranty - Aluminum Body Panels 5 years Unlimited miles
Warranty - Corrosion - Sheet Metal (Perforation Only Excluding Aluminum) 5 years Unlimited miles
Warranty - Roadside Assistance Program 5 years 60,000 miles
Regular Cab Exterior Dimensions
Cab style Regular Cab
Pickup box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Drive system 4x2 4x4 4x2 4x4 4x2 4x4
Wheelbase - - 122.4 in. 122.4 in. 141.1 in. 141.1 in.
Overall length - - 209.3 in. 209.3 in. 227.9 in. 227.9 in.
Cab height - - 75.5 in. 76.9 in. 75.1 in. 76.9 in.
Width - Excluding mirrors - - 79.9 in. 79.9 in. 79.9 in. 79.9 in.
Width - Including standard mirrors - - 96.8 in. 96.8 in. 96.8 in. 96.8 in.
Width - Standard mirrors folded - - 83.5 in. 83.5 in. 83.5 in. 83.5 in.
Width - Including trailer tow mirrors - - 105.9 in. 105.9 in. 105.9 in. 105.9 in.
Width - Trailer tow mirrors folded - - 85.5 in. 85.5 in. 85.5 in. 85.5 in.
Track width - Front - - 67.6 in. 67.6 in. 67.6 in. 67.6 in.
Track width - Rear - - 67.6 in. 67.6 in. 67.6 in. 67.6 in.
Overhang - Front - - 37.8 in. 37.8 in. 37.8 in. 37.8 in.
Overhang - Rear - - 49.1 in. 49.1 in. 49.1 in. 49.1 in.
Angle of approach - - 24.8 degrees 24.8 degrees 24.1 degrees 25.7 degrees
Angle of departure - - 24.6 degrees 27.1 degrees 24.7 degrees 26.8 degrees
Ramp breakover angle - - 22.1 degrees 24.7 degrees 19.3 degrees 22.1 degrees
Ground clearance - - 8.8 in. 9.4 in. 8.6 in. 9.4 in.
Open tailgate to ground - - 34.7 in. 36.9 in. 34.8 in. 36.5 in.
Front bumper to back of cab - - 121.5 in. 121.5 in. 121.5 in. 121.5 in.
Cab style SuperCab
Pickup box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Drive system 4x2 4x4 4x2 4x4 4x2 4x4
Wheelbase - - 145.0 in. 145.0 in. 163.7 in. 163.7 in.
Overall length - - 231.9 in. 231.9 in. 250.5 in. 250.5 in.
Cab height - - 75.5 in. 77.2 in. 75.5 in. 77.0 in.
Width - Excluding mirrors - - 79.9 in. 79.9 in. 79.9 in. 79.9 in.
Width - Including standard mirrors - - 96.8 in. 96.8 in. 96.8 in. 96.8 in.
Width - Standard mirrors folded - - 83.5 in. 83.5 in. 83.5 in. 83.5 in.
Width - Including trailer tow mirrors - - 105.9 in. 105.9 in. 105.9 in. 105.9 in.
Width - Trailer tow mirrors folded - - 85.5 in. 85.5 in. 85.5 in. 85.5 in.
Track width - Front - - 67.6 in. 67.6 in. 67.6 in. 67.6 in.
Track width - Rear - - 67.6 in. 67.6 in. 67.6 in. 67.6 in.
Overhang - Front - - 37.8 in. 37.8 in. 37.8 in. 37.8 in.
Overhang - Rear - - 49.1 in. 49.1 in. 49.1 in. 49.1 in.
Angle of approach - - 24.4 degrees 25.8 degrees 24.5 degrees 26.1 degrees
Angle of departure - - 24.0 degrees 26.1 degrees 24.4 degrees 26.0 degrees
Ramp breakover angle - - 18.5 degrees 21.1 degrees 16.8 degrees 19.0 degrees
Ground clearance - - 8.7 in. 9.4 in. 8.7 in. 9.3 in.
Open tailgate to ground - - 34.1 in. 35.9 in. 34.5 in. 35.7 in.
Front bumper to back of cab - - 144.1 in. 144.1 in. 144.1 in. 144.1 in.
Cab style SuperCrew
Pickup box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Drive system 4x2 4x4 4x2 4x4 4x2 4x4
Wheelbase 145.0 in. 145.0 in. 156.8.0 in. 156.8 in. - -
Overall length 231.9 in. 231.9 in. 243.7 in. 243.7 in. - -
Cab height 75.6 in. 77.2 in. 75.7 in. 77.3 in. - -
Width - Excluding mirrors 79.9 in. 79.9 in. 79.9 in. 79.9 in. - -
Width - Including standard mirrors 96.8 in. 96.8 in. 96.8 in. 96.8 in. - -
Width - Standard mirrors folded 83.5 in. 83.5 in. 83.5 in. 83.5 in. - -
Width - Including trailer tow mirrors 105.9 in. 105.9 in. 105.9 in. 105.9 in. - -
Width - Trailer tow mirrors folded 85.5 in. 85.5 in. 85.5 in. 85.5 in. - -
Track width - Front 67.6 in. 67.6 in. 67.6 in. 67.6 in. - -
Track width - Rear 67.6 in. 67.6 in. 67.6 in. 67.6 in. - -
Overhang - Front 37.8 in. 37.8 in. 37.8 in. 37.8 in. - -
Overhang - Rear 49.1 in. 49.1 in. 49.1 in. 49.1 in. - -
Angle of approach 24.1 degrees 25.5 degrees 23.8 degrees 25.5 degrees - -
Angle of departure 23.8 degrees 26.0 degrees 24.5 degrees 26.4 degrees - -
Ramp breakover angle 18.3 degrees 21.0 degrees 17.2 degrees 19.7 degrees - -
Ground clearance 8.5 in. 9.4 in. 8.4 in. 9.3 in. - -
Open tailgate to ground 34.0 in. 35.7 in. 34.6 in. 36.1 in. - -
Front bumper to back of cab 155.9 in. 155.9 in. 155.9 in. 155.9 in. - -
Exterior Dimensions - Cargo Box
Cargo box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Inside Length (at floor) 67.1 in. 78.9 in. 97.6 in.
Width between wheelhouses 50.6 in. 50.6 in. 50.6 in.
Inside Height 21.4 in. 21.4 in. 21.4 in.
Cargo box volume 52.8 cu. ft. 62.3 cu. ft. 77.4 cu. ft.
Interior Dimensions
Cab style Regular Cab SuperCab SuperCrew
Head room - Front 40.8 in. 40.8 in. 40.8 in.
Head room - Rear - 40.3 in. 40.4 in.
Shoulder room - Front 66.7 in. 66.7 in. 66.7 in.
Shoulder room - Rear - 65.8 in. 65.9 in.
Hip room - Front 62.5 in. 62.5 in. 62.5 in.
Hip room - Rear - 64.7 in. 64.7 in.
Max Legroom - Front 43.9 in. 43.9 in. 43.9 in.
Leg room - Rear - 33.5 in. 43.6 in.
Passengers
Cab style Regular Cab SuperCab SuperCrew
Seating capacity 3 5,6 5,6
Fuel
Fuel capacity - Standard Range 23 gallons 23 gallons 23 gallons
Fuel Capacity - Extended Range 36 gallons* 36 gallons 36 gallons
* Not available with 122"WB
Curb Weight
Cab style Regular Cab
Pickup box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Drive system 4x2 4x4 4x2 4x4 4x2 4x4
Base Curb Weight - 2.7L EcoBoost® V6 - - 4,139 lbs. 4,409 lbs. 4,231 lbs. 4,514 lbs.
Base Curb Weight - 3.5L EcoBoost® V6 - - - - 4,420 lbs. 4,642 lbs.
Base Curb Weight - 3.5L Ti-VCT V6 - - 4,051 lbs. 4,305 lbs. 4,152 lbs. 4,393 lbs.
Base Curb Weight - 5.0L Ti-VCT V8 - - 4,252 lbs. 4,516 lbs. 4,360 lbs. 4,612 lbs.
Cab style Super Cab
Pickup box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Drive system 4x2 4x4 4x2 4x4 4x2 4x4
Base Curb Weight - 2.7L EcoBoost® V6 - - 4,479 lbs. 4,782 lbs. 4,621 lbs. -
Base Curb Weight - 3.5L EcoBoost® V6 - - 4,581 lbs. 4,844 lbs. 4,738 lbs. 5,009 lbs.
Cab style Super Crew
Pickup box style 5.5-ft. Styleside 6.5-ft. Styleside 8.0-ft. Styleside
Drive system 4x2 4x4 4x2 4x4 4x2 4x4
Base Curb Weight - 2.7L EcoBoost® V6 4,560 lbs. 4,782 lbs. 4,585 lbs. - - -
Base Curb Weight - 3.5L EcoBoost® V6 4,629 lbs. 4,890 lbs. 4,685 lbs. 4,937 lbs. - -
Base Curb Weight - 3.5L Ti-VCT V6 4,489 lbs. 4,729 lbs. - - - -
Base Curb Weight - 5.0L Ti-VCT V8 4,590 lbs. 4,850 lbs. 4,623 lbs. 4,895 lbs. - -
Engine Specifications
Engine type 2.7L EcoBoost® V6 3.5L EcoBoost® V6 3.5L Ti-VCT V6 5.0L Ti-VCT V8
Engine Control System Electronic Electronic Electronic Electronic
Horsepower (SAE net@rpm) 325 @ 5750 rpm 365 @ 5000 rpm 282 @ 6250 rpm 385 @ 5750 rpm
Torque (lb.-ft. @rpm) 375 @ 3000 rpm 420 @ 2500 rpm 253 @ 4250 rpm 387 @ 3850 rpm
Compression ratio 10.0:1 10.0:1 10.8:1 10.5:1
Bore (in.) 3.27 3.64 3.64 3.63
Stroke (in.) 3.27 3.45 3.45 3.65
Displacement (cu. in.) 164 213 213 302
Main bearings 4 4 4 5
Valve operation Roller Finger Follower Direct Acting Mechanical Bucket (DAMB) Direct Acting Mechanical Bucket (DAMB) Roller Finger Follower
Fuel delivery High Pressure Direct Injection High Pressure Direct Injection Sequential multi-port electronic injection Sequential multi-port electronic injection
Oil Capacity (qt.) 6 6 6 6
Coolant Capacity (qt.) 16.4 15.6 15.3 15.9
Fuel Economy - 4x2 (city/highway/combined) 19/26/22 17/24/20 18/25/20 15/22/18
Fuel Economy - 4x2 Payload Package (city/highway/combined) 18/24/21 16/22/18 - 14/20/16
Fuel Economy - 4x4 (city/highway/combined) 18/23/20 16/22/18 17/23/19 15/21/17
Fuel Economy - 4x4 Payload Package (city/highway/combined) 18/22/19 15/20/17 - 14/19/16
Transmission type Electronic 6-speed automatic transmission Electronic 6-speed automatic transmission Electronic 6-speed automatic transmission Electronic 6-speed automatic transmission
Transmission - Tow Haul Mode Standard Standard Standard Standard
Transmission - SelectShift® w/Progressive Range Select Available Available - Available
Engine block material Compacted Graphite Iron Aluminum Aluminum Aluminum
Cylinder head material Aluminum Aluminum Aluminum Aluminum
Chassis Specifications
Front suspension Independent double-wishbone with coil-over shock and stamped lower control arm
Rear suspension Leaf spring/solid axle
Front and rear shocks Heavy-duty gas-pressurized
Brakes Power 4-wheel anti-lock vented disc
Steering Electric Power-Assisted
Towing Capabilities
Conventional/Fifth-Wheel Towing - Maximum Loaded Trailer Weight - Automatic Transmission*
Regular Cab
Wheelbase     122.4 in. 122.4 in. 141.1 in. 141.1 in. 145.0 in. 145.0 in. 156.8 in. 156.8 in. 163.7 in. 163.7 in.
Drive Type     4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4
Engine Axle Ratio GCWR (lbs.)         - - - - - -
2.7L EcoBoost® V6 3.31 12200 7,600 lbs. - - - - - - - - -
2.7L EcoBoost® V6 3.31 12300 - - 7,600 lbs. - - - - - - -
2.7L EcoBoost® V6 3.31 12500 - - - - - - - - - -
2.7L EcoBoost® V6 3.31 12600 - - - - - - - - - -
2.7L EcoBoost® V6 3.55 12500 - 7,700 lbs. - 7,600 lbs. - - - - - -
2.7L EcoBoost® V6 3.55 12700 - - - - - - - - - -
2.7L EcoBoost® V6 3.55 12800 - - - - - - - - - -
2.7L EcoBoost® V6 3.73 13100 8,500 lbs. - 8,400 lbs. - - - - - - -
2.7L EcoBoost® V6 3.73 13300 - 8,500 lbs. 8,500 lbs. * 8,400 lbs. - - - - - -
3.5L Ti-VCT V6 3.55 9400 5,000 lbs. - - - - - - - - -
3.5L Ti-VCT V6 3.55 9500 - - 5,000 lbs. - - - - - - -
3.5L Ti-VCT V6 3.55 9700 - 5,000 lbs. - - - - - - - -
3.5L Ti-VCT V6 3.73 12000 7,600 lbs. - - - - - - - - -
3.5L Ti-VCT V6 3.73 12100 - - 7,600 lbs. - - - - - - -
3.5L Ti-VCT V6 3.73 12200 - 7,500 lbs. - 7,400 lbs. - - - - - -
3.5L EcoBoost® V6 3.15 15500 - - 10,600 lbs. - - - - - - -
3.5L EcoBoost® V6 3.15 15800 - - - - - - - - - -
3.5L EcoBoost® V6 3.15 15900 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 15800 - - - 10,700 lbs. - - - - - -
3.5L EcoBoost® V6 3.31 16000 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 16100 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 16200 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 15800 - - - 10,700 lbs. - - - - - -
3.5L EcoBoost® V6 3.55 16000 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16100 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16200 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16900 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 17000 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 17100 - - 12,200 lbs. 12,000 lbs. - - - - - -
3.5L EcoBoost® V6 3.73 17000 - - - 11,800 lbs. ** - - - - - -
3.5L EcoBoost® V6 3.73 17100 - - 12,000 lbs. † 11,800 lbs. † - - - - - -
5.0L Ti-VCT V8 3.31 13000 8,300 lbs. - - - - - - - - -
5.0L Ti-VCT V8 3.31 13200 - 8,300 lbs. - - - - - - - -
5.0L Ti-VCT V8 3.31 13900 - - 9,000 lbs. - - - - - - -
5.0L Ti-VCT V8 3.31 14100 - - - 9,000 lbs. - - - - - -
5.0L Ti-VCT V8 3.31 14200 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 14300 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 13200 - 8,300 lbs. - - - - - - - -
5.0L Ti-VCT V8 3.55 13800 9,100 lbs. - - - - - - - - -
5.0L Ti-VCT V8 3.55 14100 - - - 9,000 lbs. - - - - - -
5.0L Ti-VCT V8 3.55 14400 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 14500 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 14900 - - 10,000 lbs. - - - - - - -
5.0L Ti-VCT V8 3.55 15200 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 15300 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 14600 - 9,600 lbs. - - - - - - - -
5.0L Ti-VCT V8 3.73 16000 - - 11,000 lbs. † - - - - - - -
5.0L Ti-VCT V8 3.73 16100 - - - 10,900 lbs. ** - - - - - -
5.0L Ti-VCT V8 3.73 16200 - - - 11,100 lbs. † - - - - - -
SuperCab
Wheelbase     122.4 in. 122.4 in. 141.1 in. 141.1 in. 145.0 in. 145.0 in. 156.8 in. 156.8 in. 163.7 in. 163.7 in.
Drive Type     4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4
Engine Axle Ratio GCWR (lbs.)
2.7L EcoBoost® V6 3.31 12200 - - - - - - - - - -
2.7L EcoBoost® V6 3.31 12300 - - - - - - - - - -
2.7L EcoBoost® V6 3.31 12500 - - - - 7,600 lbs. - - - - -
2.7L EcoBoost® V6 3.31 12600 - - - - - - - - 7,600 lbs. -
2.7L EcoBoost® V6 3.55 12500 - - - - - - - - - -
2.7L EcoBoost® V6 3.55 12700 - - - - - 7,500 lbs. - - - -
2.7L EcoBoost® V6 3.55 12800 - - - - - - - - - -
2.7L EcoBoost® V6 3.73 13100 - - - - 8,200 lbs. - - - 8,100 lbs. -
2.7L EcoBoost® V6 3.73 13300 - - - - 8,300 lbs. * 8,100 lbs. - - 8,200 lbs. -
3.5L Ti-VCT V6 3.55 9500 - - - - - - - - - -
3.5L Ti-VCT V6 3.55 9600 - - - - - - - - - -
3.5L Ti-VCT V6 3.55 9800 - - - - 5,000 lbs. - - - - -
3.5L Ti-VCT V6 3.73 12000 - - - - - - - - - -
3.5L Ti-VCT V6 3.73 12100 - - - - - - - - - -
3.5L Ti-VCT V6 3.73 12200 - - - - 7,400 lbs. 7,200 lbs. - - - -
3.5L EcoBoost® V6 3.15 15800 - - - - 10,700 lbs. - - - - -
3.5L EcoBoost® V6 3.15 15900 - - - - - - - - 10,600 lbs. -
3.5L EcoBoost® V6 3.31 15800 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 16000 - - - - - 10,600 lbs. - - - -
3.5L EcoBoost® V6 3.31 16100 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 16200 - - - - - - - - - 10,700 lbs.
3.5L EcoBoost® V6 3.55 15800 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16000 - - - - - 10,600 lbs. - - - -
3.5L EcoBoost® V6 3.55 16100 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16200 - - - - - - - - - 10,700 lbs.
3.5L EcoBoost® V6 3.55 16900 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 17000 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 17100 - - - - 12,000 lbs. 11,700 lbs. - - 11,800 lbs. 11,600 lbs.
3.5L EcoBoost® V6 3.73 17000 - - - - - - - - - -
3.5L EcoBoost® V6 3.73 17100 - - - - - - - - 11,700 lbs. † 11,500 lbs. †
5.0L Ti-VCT V8 3.31 13000 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 13200 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 13900 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 14200 - - - - 9,100 lbs. - - - - -
5.0L Ti-VCT V8 3.31 14300 - - - - - 9,000 lbs. - - 9,100 lbs. 8,800 lbs.
5.0L Ti-VCT V8 3.55 13200 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 13800 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 14100 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 14400 - - - - - 9,000 lbs. - - - -
5.0L Ti-VCT V8 3.55 14500 - - - - - - - - - 9,000 lbs.
5.0L Ti-VCT V8 3.55 14900 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 15200 - - - - 10,100 lbs. - - - - -
5.0L Ti-VCT V8 3.55 15300 - - - - - - - - 10,100 lbs. -
5.0L Ti-VCT V8 3.73 14600 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 16000 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 16100 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 16200 - - - - - 10,900 lbs. - - 10,900 lbs. † 10,700 lbs.
SuperCrew
Wheelbase     122.4 in. 122.4 in. 141.1 in. 141.1 in. 145.0 in. 145.0 in. 156.8 in. 156.8 in. 163.7 in. 163.7 in.
Drive Type     4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4
Engine Axle Ratio GCWR (lbs.)
2.7L EcoBoost® V6 3.31 12200 - - - - - - - - - -
2.7L EcoBoost® V6 3.31 12300 - - - - - - - - - -
2.7L EcoBoost® V6 3.31 12500 - - - - - - - - - -
2.7L EcoBoost® V6 3.31 12600 - - - - 7,600 lbs. - 7,600 lbs. - - -
2.7L EcoBoost® V6 3.55 12500 - - - - - - - - - -
2.7L EcoBoost® V6 3.55 12700 - - - - - - - - - -
2.7L EcoBoost® V6 3.55 12800 - - - - - 7,500 lbs. - - - -
2.7L EcoBoost® V6 3.73 13100 - - - - 8,100 lbs. - 8,100 lbs. - - -
2.7L EcoBoost® V6 3.73 13300 - - - - 8,200 lbs. * 8,000 lbs. 8,200 lbs. * - - -
3.5L Ti-VCT V6 3.55 9500 - - - - - - - - - -
3.5L Ti-VCT V6 3.55 9600 - - - - - - - - - -
3.5L Ti-VCT V6 3.55 9900 - - - - 5,000 lbs. - - - - -
3.5L Ti-VCT V6 3.73 12000 - - - - - - - - - -
3.5L Ti-VCT V6 3.73 12100 - - - - - - - - - -
3.5L Ti-VCT V6 3.73 12200 - - - - 7,300 lbs. 7,100 lbs. - - - -
3.5L EcoBoost® V6 3.15 15800 - - - - 10,600 lbs. - - - - -
3.5L EcoBoost® V6 3.15 15900 - - - - - - 10,700 lbs. - - -
3.5L EcoBoost® V6 3.31 15800 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 16000 - - - - - - - - - -
3.5L EcoBoost® V6 3.31 16100 - - - - - 10,700 lbs. - 10,600 lbs. - -
3.5L EcoBoost® V6 3.31 16200 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 15800 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16000 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16100 - - - - - 10,700 lbs. - 10,600 lbs. - -
3.5L EcoBoost® V6 3.55 16200 - - - - - - - - - -
3.5L EcoBoost® V6 3.55 16900 - - - - - 11,500 lbs. - - - -
3.5L EcoBoost® V6 3.55 17000 - - - - 11,800 lbs. - - - - -
3.5L EcoBoost® V6 3.55 17100 - - - - - - 11,900 lbs. 11,600 lbs. - -
3.5L EcoBoost® V6 3.73 17000 - - - - - - - 11,400 lbs. ** - -
3.5L EcoBoost® V6 3.73 17100 - - - - - - 11,700 lbs. †** 11,400 lbs. † - -
5.0L Ti-VCT V8 3.31 13000 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 13200 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 13900 - - - - - - - - - -
5.0L Ti-VCT V8 3.31 14200 - - - - 9,100 lbs. - 9,100 lbs. - - -
5.0L Ti-VCT V8 3.31 14300 - - - - - 8,900 lbs. - 8,900 lbs. - -
5.0L Ti-VCT V8 3.55 13200 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 13800 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 14100 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 14400 - - - - - 9,000 lbs. - - - -
5.0L Ti-VCT V8 3.55 14500 - - - - - - - 9,100 lbs. - -
5.0L Ti-VCT V8 3.55 14900 - - - - - - - - - -
5.0L Ti-VCT V8 3.55 15200 - - - - 10,100 lbs. - 10,100 lbs. - - -
5.0L Ti-VCT V8 3.55 15300 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 14600 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 16000 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 16100 - - - - - - - - - -
5.0L Ti-VCT V8 3.73 16200 - - - - - 10,800 lbs. - 10,800 lbs. - -
Vehicles equipped with 5.5' box will accept a fifth-wheel hitch, but current fifth-wheel trailer designs are not compatible with these models (145" wheelbase SuperCrew)
*Requires 2.7L EcoBoost® V6® Payload Package
**Requires Heavy Duty Payload Package with 17" wheels
†Requires Heavy Duty Payload Package with 18" wheels

Payload Package Selector
Maximum Payload
Regular Cab
Wheelbase   122.4 in. 122.4 in. 141.1 in. 141.1 in. 145.0 in. 145.0 in. 156.8 in. 156.8 in. 163.7 in. 163.7 in.
Drive Type   4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4
Engine GVWR (lbs.)
2.7L EcoBoost® V6 6010 1,820 lbs. - - - - - - - - -
2.7L EcoBoost® V6 6050 - 1,590 lbs. - - - - - - - -
2.7L EcoBoost® V6 6100 - - 1,820 lbs. - - - - - - -
2.7L EcoBoost® V6 6250 - - - 1,690 lbs. - - - - - -
2.7L EcoBoost® V6 6350 - - - - - - - - - -
2.7L EcoBoost® V6 6500 - - - - - - - - - -
2.7L EcoBoost® V6 6650 - - 2,210 lbs. * - - - - - - -
2.7L EcoBoost® V6 6750 - - - - - - - - - -
2.7L EcoBoost® V6 6800 - - - 2,110 lbs. * - - - - - -
2.7L EcoBoost® V6 6900 - - - - - - - - - -
2.7L EcoBoost® V6 7000 - - - - - - - - - -
3.5L Ti-VCT V6 6010 1,910 lbs. - - - - - - - - -
3.5L Ti-VCT V6 6050 - 1,700 lbs. - - - - - - - -
3.5L Ti-VCT V6 6100 - - 1,900 lbs. 1,660 lbs. - - - - - -
3.5L Ti-VCT V6 6150 - - - - - - - - - -
3.5L Ti-VCT V6 6300 - - - - - - - - - -
3.5L Ti-VCT V6 6350 - - - - - - - - - -
3.5L EcoBoost® V6 6800 - - - - - - - - - -
3.5L EcoBoost® V6 6900 - - - - - - - - - -
3.5L EcoBoost® V6 7000 - - - - - - - - - -
3.5L EcoBoost® V6 7050 - - 2,580 lbs. 2,360 lbs. - - - - - -
3.5L EcoBoost® V6 7600 - - 3,010 lbs. ** 2,800 lbs. ** - - - - - -
3.5L EcoBoost® V6 7850 - - 3,240 lbs. † 3,010 lbs. † - - - - - -
5.0L Ti-VCT V8 6200 1,900 lbs. - - - - - - - - -
5.0L Ti-VCT V8 6400 - 1,830 lbs. - - - - - - - -
5.0L Ti-VCT V8 6750 - - 2,340 lbs. - - - - - - -
5.0L Ti-VCT V8 6800 - - - - - - - - - -
5.0L Ti-VCT V8 6900 - - - - - - - - - -
5.0L Ti-VCT V8 6950 - - - 2,290 lbs. - - - - - -
5.0L Ti-VCT V8 7000 - - - - - - - - - -
5.0L Ti-VCT V8 7050 - - - - - - - - - -
5.0L Ti-VCT V8 7600 - - 3,040 lbs. ** 2,810 lbs. ** - - - - - -
5.0L Ti-VCT V8 7850 - - 3,270 lbs.† 3,040 lbs.† - - - - - -
SuperCab
Wheelbase   122.4 in. 122.4 in. 141.1 in. 141.1 in. 145.0 in. 145.0 in. 156.8 in. 156.8 in. 163.7 in. 163.7 in.
Drive Type   4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4
Engine GVWR (lbs.)
2.7L EcoBoost® V6 6010 - - - - - - - - - -
2.7L EcoBoost® V6 6050 - - - - - - - - - -
2.7L EcoBoost® V6 6100 - - - - - - - - - -
2.7L EcoBoost® V6 6250 - - - - 1,720 lbs. - - - - -
2.7L EcoBoost® V6 6350 - - - - - - - - - -
2.7L EcoBoost® V6 6500 - - - - - 1,660 lbs. - - 1,830 lbs. -
2.7L EcoBoost® V6 6650 - - - - - - - - - -
2.7L EcoBoost® V6 6750 - - - - 2,120 lbs. * - - - - -
2.7L EcoBoost® V6 6800 - - - - - - - - - -
2.7L EcoBoost® V6 6900 - - - - - - - - 2,160 lbs. * -
2.7L EcoBoost® V6 7000 - - - - - 2,110 lbs. * - - - -
3.5L Ti-VCT V6 6010 - - - - - - - - - -
3.5L Ti-VCT V6 6050 - - - - - - - - - -
3.5L Ti-VCT V6 6100 - - - - 1,660 lbs. - - - - -
3.5L Ti-VCT V6 6150 - - - - - - - - - -
3.5L Ti-VCT V6 6300 - - - - - 1,600 lbs. - - - -
3.5L Ti-VCT V6 6350 - - - - - - - - - -
3.5L EcoBoost® V6 6800 - - - - - - - - - -
3.5L EcoBoost® V6 6900 - - - - 2,270 lbs. - - - - -
3.5L EcoBoost® V6 7000 - - - - - - - - - -
3.5L EcoBoost® V6 7050 - - - - - 2,150 lbs. - - 2,260 lbs. 1,990 lbs.
3.5L EcoBoost® V6 7600 - - - - - - - - 2,720 lbs. ** 2,480 lbs. **
3.5L EcoBoost® V6 7850 - - - - - - - - 2,950 lbs. † 2,710 lbs. †
5.0L Ti-VCT V8 6200 - - - - - - - - - -
5.0L Ti-VCT V8 6400 - - - - - - - - - -
5.0L Ti-VCT V8 6750 - - - - - - - - - -
5.0L Ti-VCT V8 6800 - - - - - - - - - -
5.0L Ti-VCT V8 6900 - - - - 2,310 lbs. - - - - -
5.0L Ti-VCT V8 6950 - - - - - - - - - -
5.0L Ti-VCT V8 7000 - - - - - - - - 2,290 lbs. 2,010 lbs.
5.0L Ti-VCT V8 7050 - - - - - 2,200 lbs. - - - -
5.0L Ti-VCT V8 7600 - - - - - - - - 2,740 lbs. ** 2,490 lbs. **
5.0L Ti-VCT V8 7850 - - - - - - - - 2,970 lbs. † 2,730 lbs. †
SuperCrew
Wheelbase   122.4 in. 122.4 in. 141.1 in. 141.1 in. 145.0 in. 145.0 in. 156.8 in. 156.8 in. 163.7 in. 163.7 in.
Drive Type   4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4 4x2 4x4
Engine GVWR (lbs.)
2.7L EcoBoost® V6 6010 - - - - - - - - - -
2.7L EcoBoost® V6 6050 - - - - - - - - - -
2.7L EcoBoost® V6 6100 - - - - - - - - - -
2.7L EcoBoost® V6 6250 - - - - 1,640 lbs. - - - - -
2.7L EcoBoost® V6 6350 - - - - - - 1,710 lbs. - - -
2.7L EcoBoost® V6 6500 - - - - - 1,630 lbs. - - - -
2.7L EcoBoost® V6 6650 - - - - 1,950 lbs. * - - - - -
2.7L EcoBoost® V6 6750 - - - - - - - - - -
2.7L EcoBoost® V6 6800 - - - - - - 2,080 lbs. * - - -
2.7L EcoBoost® V6 6900 - - - - - 1,960 lbs. * - - - -
2.7L EcoBoost® V6 7000 - - - - - - - - - -
3.5L Ti-VCT V6 6010 - - - - - - - - - -
3.5L Ti-VCT V6 6050 - - - - - - - - - -
3.5L Ti-VCT V6 6100 - - - - - - - - - -
3.5L Ti-VCT V6 6150 - - - - 1,610 lbs. - - - - -
3.5L Ti-VCT V6 6300 - - - - - - - - - -
3.5L Ti-VCT V6 6350 - - - - - 1,570 lbs. - - - -
3.5L EcoBoost® V6 6800 - - - - 2,120 lbs. - - - - -
3.5L EcoBoost® V6 6750 (Limited) - - - - 1720 lbs. 1450 lbs. - - - -
3.5L EcoBoost® V6 7000 - - - - - 2,060 lbs. 2,260 lbs. - - -
3.5L EcoBoost® V6 7050 - - - - - - - 2,060 lbs. - -
3.5L EcoBoost® V6 7600 - - - - - - 2,660 lbs. ** 2,420 lbs. ** - -
3.5L EcoBoost® V6 7850 - - - - - - 2,890 lbs. † 2,650 lbs. † - -
5.0L Ti-VCT V8 6200 - - - - - - - - - -
5.0L Ti-VCT V8 6400 - - - - - - - - - -
5.0L Ti-VCT V8 6750 - - - - - - - - - -
5.0L Ti-VCT V8 6800 - - - - 2,160 lbs. - - - - -
5.0L Ti-VCT V8 6900 - - - - - - - - - -
5.0L Ti-VCT V8 6950 - - - - - - 2,280 lbs. - - -
5.0L Ti-VCT V8 7000 - - - - - 2,100 lbs. - - - -
5.0L Ti-VCT V8 7050 - - - - - - - 2,100 lbs. - -
5.0L Ti-VCT V8 7600 - - - - - - 2,680 lbs. ** 2,430 lbs. ** - -
5.0L Ti-VCT V8 7850 - - - - - - 2,910 lbs. † 2,660 lbs. † - -
*Requires 2.7L EcoBoost® V6® Payload Package
**Requires Heavy Duty Payload Package with 17" wheels
†Requires Heavy Duty Payload Package with 18" wheels

Welcome AXZ Plan participant.

Now you can view exclusive price savings on our Build & Price Shopping Tool

Note: AXZ Plan pricing information is not available on all Ford websites. In addition, some vehicles, trims or options you select may not qualify for AXZ Plans. Also, some dealers may choose not to participate in AXZ Plan pricing. Contact your local dealer to determine their level of participation in the Program and final vehicle pricing.

What happens if I close this site before I’m finished?
If you close your window or tab, you must re-access the site through the AXZ Plan Pricing website to ensure that all eligible plan pricing is visible. If you need additional information concerning the AXZ Plans, please refer back to you’re AXZ Plan Pricing website for complete details.

AXZ Plan pricing, including AXZ Plan option pricing, is exclusively for eligible Ford Motor Company employees, friends and family-members of eligible employees, and Ford Motor Company eligible partners. Restrictions apply. See your Ford or Lincoln dealer for complete details and qualifications. Ford Motor Company reserves the right to modify the terms of this Plan at any time.
View Additional Disclosures

Additional Disclosures

X
Information is provided on an "as is" basis and could include technical, typographical or other errors. Ford makes no warranties, representations, or guarantees of any kind, express or implied, including but not limited to, accuracy, currency, or completeness, the operation of the Site, the information, materials, content, availability, and products. Ford reserves the right to change product specifications, pricing and equipment at any time without incurring obligations. Your Ford dealer is the best source of the most up-to-date information on Ford vehicles.
1. Starting MSRP excludes destination/delivery charge, taxes, title and registration. Optional equipment not included. Starting A, Z and X Plan price is for qualified, eligible customers and excludes document fee, destination/delivery charge, taxes, title and registration. Not all vehicles qualify for A, Z or X Plan. All Mustang Shelby GT350 and Shelby GT350R prices exclude gas guzzler tax.
2. EPA-estimated city/hwy mpg for the model indicated. See fueleconomy.gov for fuel economy of other engine/transmission combinations. Actual mileage will vary. On plug-in hybrid models and electric models, fuel economy is stated in MPGe. MPGe is the EPA equivalent measure of gasoline fuel efficiency for electric mode operation.
3. When properly equipped.
10. Driver Assist Features are supplemental and do not replace the driver's attention, judgment and need to control the vehicle.
15. Classes are: Small Plug-in Hybrid Vehicles (C-MAX Energi); Small Hybrid Vehicles (C-MAX Hybrid); Subcompact Cars (Fiesta); High-Performance Subcompact Cars (Fiesta ST); Small Sedans and Hatchbacks (Focus); High-Performance Small Cars (Focus ST); Small Electric Vehicles (Focus Electric); Midsize Sedans (Fusion); Midsize Hybrid Sedans (Fusion Hybrid); Midsize Plug-in Hybrid Sedans (Fusion Energi); Full-Size Sedans (Taurus); 300+ HP Sports Cars (Mustang); Small Utilities (Escape); Midsize Utilities (Edge); Large Utilities (Flex and Explorer); Extended Utilities (Expedition); Full-Size Pickups under 8,500 lbs. GVWR, Non-Hybrid (F-150); Full-Size Pickups over 8,500 lbs. GVWR (Super Duty); Full-Size Vans (Transit/E-Series); Small Cargo Vans (Transit Connect); 6-7 Classic Conventional Cabs (Medium Duty) based on Ford segmentation.
20. For dealer ordered vehicles, the vehicle has already been ordered by the dealer and is in the process of being manufactured by the factory. If you are interested in the vehicle marked "Dealer Ordered", contact the dealership for a delivery estimate.
27. SYNC® is an optional feature. Don’t drive while distracted. Use voice-operated systems when possible; don’t use handheld devices while driving. Some features may be locked out while the vehicle is in gear. Not all features are compatible with all phones. Message and data rates may apply. Optional Navigation System map updates cannot be received via Wi-fi® and require a separate update.
28. The vehicle's electrical system (including the battery), the wireless service provider's signal and a connected mobile phone must all be available and operating for 911 Assist to function properly. These systems may become damaged in a crash. The paired mobile phone must be connected to SYNC, and the 911 Assist feature enabled, in order for 911 to be dialed. When the feature is ON, 911 Assist uses your paired and connected mobile phone to assist occupants to contact emergency services by dialing 911 if your airbag deploys or, on certain vehicles, if the emergency fuel pump shut-off is activated. Aftermarket on-board diagnostic devices may interfere with various vehicle systems including Vehicle Health Report and 911 Assist. To avoid interference, remove the device or contact the device maker for more information on compatibility.
34. Available Feature. SiriusXM audio and data services each require a subscription sold separately, or as a package, by Sirius XM Radio Inc. If you decide to continue service after your trial, the subscription plan you choose will automatically renew thereafter and you will be charged according to your chosen payment method at then-current rates. Fees and taxes apply. To cancel you must call SiriusXM at 1-866-635-2349. See SiriusXM Customer Agreement for complete terms at www.siriusxm.com. All fees and programming subject to change. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.
39. Remember that even advanced technology cannot overcome the laws of physics. It's always possible to lose control of a vehicle due to inappropriate driver input for the conditions.
43. Android is a trademark of Google Inc. iPhone® is a registered trademark of Apple Inc. The BlackBerry and RIM families of related marks, images and symbols are the exclusive properties and trademarks of Research In Motion Limited.
48. You must have a Bluetooth®-enabled phone paired to your SYNC® system. The Bluetooth word mark is a trademark of the Bluetooth SIG, Inc. HD Radio is a proprietary trademark of iBiquity Digital Corp. iPad®, iPod®, iTunes®, iPhone®, and Siri® are registered trademarks of Apple Inc. The term Wi-Fi® is a registered trademark of the Wi-Fi Alliance®. Optional Navigation System map updates cannot be received via wi-fi and require a separate update. Sony is a registered trademark of the Sony Corporation.
52. Google Maps is a trademark of Google, Inc. MapQuest is a trademark of AOL Inc.
53. PANDORA, the PANDORA logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. Used with permission. iHeartAuto is a registered trademark of Clear Channel Broadcasting, Inc. Slacker® is a registered trademark of Slacker®, Inc. Stitcher Smart Radio is a registered trademark of Stitcher, Inc. NPR and the NPR logo are registered trademarks of National Public Radio, Inc. Used with permission. Gracenote is a registered trademark of Gracenote, Inc.
63. SYNC® AppLinktm is available on select models and compatible with select smartphone platforms. SYNC AppLink requires any compatible apps to be installed and running on a capable smartphone while connected to Ford SYNC. SYNC AppLink is not compatible with MyFord Touch. Commands may vary by phone and AppLink software.
64. 20 Operator Assist sessions included with each one-year paid/complimentary SYNC Services subscription. Fees apply for additional sessions. See owner.Ford.com.
68. Horsepower and torque ratings achieved with 93-octane fuel.
129. SYNC Services varies by trim level and model year and may require a subscription. Traffic alerts and turn-by-turn directions available in select markets. Message and data rates may apply. Ford Motor Company reserves the right to change or discontinue this product service at any time without prior notification or incurring any future obligation.
160. Available feature. Don’t drive while distracted. Use voice-operated systems when possible; don’t use handheld devices while driving. Apple CarPlay is available on 2017 models with SYNC 3; owners of 2016 models with SYNC 3 are required to perform a software upgrade and purchase a hardware upgrade. Requires phone with compatible version of Apple iOS and active data service. SYNC does not control Apple CarPlay while in use. Apple is solely responsible for their functionality. Message and data rates may apply. Apple CarPlay,tm iPad,® iPod,® iPhone,® iTunes,® and Siri are trademarks of Apple Inc.
161. Available feature. Don’t drive while distracted. Use voice-operated systems when possible; don’t use handheld devices while driving. Android Auto is available on 2017 models with SYNC 3; owners of 2016 models with SYNC 3 are required to perform a software upgrade. Requires phone with compatible version of Android Auto and active data service. SYNC does not control Android Auto while in use. Google is solely responsible for their functionality. Message and data rates may apply. Android Auto, Google and Google Maps are trademarks of Google Inc.
163. FordPass Overall + SYNC® Connect COMBINED
FordPass, compatible with select smartphone platforms, is available via a free download. Message and data rates
may apply. SYNC® Connect, an optional feature on select 2017 model year vehicles, is required for certain features.
164. FordPass Overall STAND-ALONE
FordPass, compatible with select smartphone platforms, is available via a free download. Message and data rates
may apply.
165. SYNC® Connect STAND-ALONE
SYNC® Connect, an optional feature on select 2017 model year vehicles,
is required for certain features.
166. Roadside Assistance
Roadside assistance is included for certain Ford owners and available to everyone for a
per-service fee.
167. Apple & Google
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. Android, Google Play and the Google Play logo are trademarks of Google Inc.
168. SYNC® Applink
SYNC® Applink is compatible with select smartphone platforms and requires any compatible apps to be installed and running on a capable smartphone while connect to Ford SYNC. Commands may vary by phone and Applink software. Message and data rates may apply.
169. FordPass Park
FordPass Park is available in select cities

Recall
A recall is an action by the Company to remedy a safety concern related to a vehicle defect or regulatory requirement.
It may require that you return your vehicle to the dealer for service. If your vehicle is not affected, it may be because it was built at a different time or using a different part than the affected vehicles. Be advised that this system tracks safety and emissions recalls and Customer Satisfaction Programs for which vehicles are subject to repair in the United States. The information provided is subject to change and update. There may be temporary delays in update of information on this site due to a number of factors. For the latest information regarding the status of your vehicle or any recall program of Ford Motor Company, please contact your local dealership directly or the Customer Relationship Center.

FordPass Canada Disclaimers: (Max Farley, Canada Legal)
SYNC® Connect, an optional feature on select 2017 model year vehicles, is required for certain features. SYNC Connect includes SYNC Connect service for five years from the vehicle sale date as recorded by dealer. Subscription fees apply after five years.
SYNC® Connect, une fonctionnalité offerte en option sur certains véhicules année-modèle 2017, est requis pour pouvoir profiter de certaines autres fonctionnalités. SYNC Connect comprend le service SYNC Connect pour une période de
cinq ans à compter de la date de vente du véhicule telle que consignée par le concessionnaire. Des frais d’abonnement s’appliquent après cette période de cinq ans.
